Integrates automatic bottle washing, filling and capping.Bulk bottles are arranged in order and transported to each station through the automatic bottle sorting device.Multi-station spray bottle washing is used to rinse the bottle mouth, bottle body and bottle bottom in all directions.After washing,
Integrates filling, capping and capping in one machine.Designed for high-viscosity liquids such as glycerin.Adopts high-precision metering system to ensure accurate filling and no dripping.The equipment automatically completes operations such as capping, capping and capping.Ensures reliable sealing,
High-speed bottle washing, filling, capping and labeling production line Through ultrasonic vibration and spraying double cleaning, effectively removing internal and external impurities and dust, followed by high-temperature tunnel to complete the drying and aseptic treatment, adopts the plunger pum
Adopting precise temperature control system to ensure smooth and even filling without collapsing.Efficient cooling and plug-pressing linkage system ensures the paste to be quickly characterized without deformation.Automatic carton loading saves time and labor, realizing the whole process automation
Capable of achieving continuous filling and capping operations. Without the need for frequent manual interventionReduces downtime in production. While possessing a high operating speed. Can complete the filling and capping of a large number of products in a short period of timeMeets the demands of rapid
GDHP
Features;
The main components of this sealing machine are made of aluminum oxide, stainless steel and other materials.
The core control part of the machine adopts touch screen and PLC. The exquisite appearance better guarantees the performance and quality of the product.
3. The film pulling device adopts time control mode.
4. The heat-sealing temperature can be freely set from 80-200 degrees according to the roll film material and bottle material.
5. The heat sealing head adopts the air cylinder as the driving force.
6. The conveyor belt speed is adjustable.
Sealing machine Technical Parameters:
| Voltage | Three-phase four-wire | silent head | 6 heads (suitable for one size bottle) |
| Air source pressure | 6-8KG | Suitable material | Composite film, aluminum film |
| Production Capacity | 2000-3000 bottles/hour | Applicable bottle type | The shape and size of the sample bottle are designed according to the specifications provided by the buyer |
| Air pressure | 5KG | Power supply | 50HZ 380V 9KW |
| Host machine size | 1600*1000*1800 (conveyor belt with 2.5 meters) |
Features;
The main components of this sealing machine are made of aluminum oxide, stainless steel and other materials.
The core control part of the machine adopts touch screen and PLC. The exquisite appearance better guarantees the performance and quality of the product.
3. The film pulling device adopts time control mode.
4. The heat-sealing temperature can be freely set from 80-200 degrees according to the roll film material and bottle material.
5. The heat sealing head adopts the air cylinder as the driving force.
6. The conveyor belt speed is adjustable.
Sealing machine Technical Parameters:
| Voltage | Three-phase four-wire | silent head | 6 heads (suitable for one size bottle) |
| Air source pressure | 6-8KG | Suitable material | Composite film, aluminum film |
| Production Capacity | 2000-3000 bottles/hour | Applicable bottle type | The shape and size of the sample bottle are designed according to the specifications provided by the buyer |
| Air pressure | 5KG | Power supply | 50HZ 380V 9KW |
| Host machine size | 1600*1000*1800 (conveyor belt with 2.5 meters) |
